24 Ports Gigabit Layer 3 Core Fiber Switches with 4 Ports 10G SFP

Name: 24 Ports Gigabit Layer 3 Core Fiber Switches with 4 Ports 10G SFP
Price: 300 USD
Availability: InStock

Classification	L3 Smart Management
PoE	None
Ethernet Port Count	8 Ports Gigabit
Gigabit SFP	24 Ports
10G SFP+	4 Ports
Installation	1U Rack

IFS5168C04TFM series 10GbE uplink Layer 3 managed Ethernet switch with 8 Gigabit Ethernet ports (multiplexed) + 24 Gigabit SFP optical port slots + 4 10GbE uplink SFP+ optical port slots, all ports support wire speed forwarding.

IFS5168C04TFM is equipped with an L3 network management function, supports IPV4/IPV6 static/dynamic route forwarding, complete security protection mechanism, perfect ACL/QoS policy, and rich VLAN function, which is easy to manage and maintain. Supports a variety of network redundancy protocols STP/RSTP/MSTP (<50ms) and ERPS (<20ms) ring network protocols to enhance link backup and network reliability when a one-way network failure, communications can be quickly restored to ensure uninterrupted communication of essential transmissions. According to the actual application needs, through the Web, CLI, SNMP, Telnet and other network management methods, IP management, port flow control, VLAN division, QoS, LACP, IGMP and DHCP, security policy and other applications and business configuration.

IFS5168C04TFM is fully compliant with industrial product design and materials; the shell is made of aluminum alloy to enhance heat dissipation efficiency; it has excellent adaptability to the industrial field environment (including mechanical stability, climate environment adaptability, electromagnetic environment adaptability, etc.); the service ports support 6KV electrostatic surge protection, the protection level reaches IP40, it supports dual redundant power supply of AC+DC, low-power consumption and fanless heat dissipation technology, MTBF average trouble-free operation time up to 35 years, and a very extended 5-year warranty. Fan cooling technology, MTBF average trouble-free working time of up to 35 years, extended 5-year warranty. Suitable for intelligent transportation, rail transportation, electric power industry, mining, oil, shipping, metallurgy, pipeline corridors, green energy construction, and other industrial scenarios to form a cost-effective, stable, and reliable communication network.


Model	IFS5168C04TFM
Port Characteristics
Downlink port	8 10/100/1000Base-T RJ45 network ports (multiplexed) 24 100/1000M SFP optical ports
Uplink port	4 1/2.5/10G SFP+ optical ports
management port	1 Console port (115200, 8, N,1)
Port Characteristics	1-8 ports 10/100/1000M adaptive, full/half duplex MDI/MDI-X adaptive
Twisted-pair transmission	10BASE-T: Cat3,4,5 UTP (≤100 meters) 100BASE-TX: Cat5 or later UTP (≤100 meters) 1000BASE-T: Cat5e or later UTP (≤100 meters)
Optical Port Characteristics	Gigabit SFP fiber optic interface, the default does not match the optical module, need to purchase another, (optional order mode/multimode, single fiber/dual fiber optical module, LC/SC)
Fiber optic cable	Multimode: 850nm/0~550M, 50μm/125μm & 62.5μm/125μm Single mode: 1310nm/0～40KM, 1550nm/0～120KM. 9.5μm/125μm
Switching Chip Parameters
Type of network management	L3 Webmaster
Network protocol	IEEE802.3 10BASE-T; IEEE802.3i 10Base-T IEEE802.3u 100Base-TX IEEE802.3x Flow Control IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-X IEEE802.3ae 10GBase-SR/LR IEEE 802.3ad port trunk with LACP IEEE 802.1D Spanning Tree protocol IEEE 802.1w Rapid Spanning Tree protocol IEEE 802.1s Multiple Spanning Tree protocol IEEE 802.1p Class of service IEEE 802.1Q VLAN tagging IEEE 802.1x Port Authentication Network Control IEEE 802.1ab LLDP
CPU	800MHz
DRAM	1Gbits
Flash	128Mbits
Forwarding mode	Store-and-forward (full wire speed)
Backplane Bandwidth	128 Gbps (non-blocking)
Packet forwarding rate @ 64byte	95.23 Mpps
MAC address table	16K
Packet Forwarding Cache	12Mbits
Frame	12Kbytes
LED	Power indicator: PWR (green); System operation light: SYS (green); Network indicator: L/A (green), Optical port indicator: SFP (green)
One-Key Restore Switch	1 pc, long press for 6 seconds and release to restore factory settings
MTBF	500,000 hours
Power Supply Characteristics
Input Voltage	AC: AC100-240V 50-60Hz (built-in) / DC: DC36-72V (external)
Power connector	AC+DC dual input power interface design, support anti-reverse connection protection; 1 set DC36-72V DC input interface; 1 set AC100-240V AC input interface
Power Consumption	Standby power consumption: <22W; full load power consumption: <45W
Matching power supply	Default built-in AC switching power supply AC: 100-240V 50-60Hz 1.0A; not supporting DC DC power supply, if you need to configure, need to buy independently.
Physical Specifications
Heat dissipation method	Fanless natural cooling
Operating Temperature/Humidity	-40 to +75°C; 5% to 90% RH non-condensing
Storage temperature/humidity	-40 to +85°C; 5% to 95% RH non-condensing
Appearance size (LWH)	44029045mm
Net/Gross Weight	<4.3kg / <4.8kg
Installation	Desktop, Rack Mount
Certifications & Warranties
Lightning Protection / Protection Rating	Port lightning protection: 6KV 8/20us; Protection level: IP40
Applicable industry standards	IEC61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge IEC 61000-4-3 (RS): 10 V/m (80~1000 MHz) IEC61000-4-4 (EFT): power line: ±4kV; data line: ±2kV IEC61000-4-5 (Surge): Power line: CM±4kV/DM±2kV; Data line: ±4kV IEC 61000-4-6 (RF conduction): 10 V (150 kHz ~ 80 MHz) IEC61000-4-8 (magnetic field at work frequency): 100A/m continuous; 1000A/m , 1s to 3s IEC61000-4-9 (pulsed magnetic field): 1000A/m IEC61000-4-10 (damped oscillations): 30A/m 1MHz IEC 61000-4-12/18 (shock wave): CM 2.5kV, DM 1kV IEC61000-4-16 (common-mode conduction): 30V continuous; 300V, 1s FCC Part 15/CISPR22 (EN55022): Class A IEC 61000-6-2 (General Industrial Standard)
Mechanical property	IEC 60068-2-6 (vibration resistance) IEC 60068-2-27 (shock resistance) IEC 60068-2-32 (free fall)
Safety certification	CE, FCC, RoHS, CCC
Warranty period	5 years
Software Management Features
Ports	Supports IEEE802.3x flow control (full-duplex), half-duplex backpressure flow control Supports forced port mode and rate Supports broadcast storm and port storm suppression Supports port traffic rate limiting with a minimum granularity of 16Kbps and a maximum of 1Gbps. Supports real-time port flow management (Flow Interval) Supports jumbo frame size control up to 16K packets Support optical port DDMI digital diagnostic function
IP routing	Support L3 network management function, support IPv4/IPv6 static/dynamic routing, support IPv4/IPv6 dual-stack management Support RIPv1/v2, RIPng Support for OSPFv1/v2, OSPFv3 Supports ARP protocol with a maximum of 1024 entries
VLAN	Support port-based VLAN (4K),IEEE802.1q Supports protocol-based VLANs Supports MAC address-based VLANs, Voice VLAN support Supports Access, Trunk, and Hybrid port configurations. Supports QinQ configuration Supports GVRP VLAN protocol
Port aggregation	Supports static aggregation and dynamic aggregation (LACP) Supports up to 14 aggregation groups, each aggregation group supports up to 8 ports
Ring Network Function	Support loop protection function Supports STP/RSTP/MSTP spanning tree protocols Support ERPS ring network (single-ring, multi-ring, intersecting ring and tangent ring configurations), ring self-healing time less than 20ms
Multicast	Supports IGMP Snooping v1/v2/v3 and up to 1024 multicast groups. Multicast VLAN Supports MVR (multicast LAN registration)
Mirroring	Supports bi-directional traffic mirroring on basic ports Supports bi-directional traffic mirroring on basic ports Supports 1-to-many mirroring Supports up to 4 port sessions
QoS	Supports port-based, 802.1P and DSCP/ToS prioritization, and supports 8 output queues per port. Supports four priority scheduling modes: Equ, SP, WRR, SP+WRR. Support Priority Mark/Remark Supports flow-based rate limiting, packet filtering, redirection
ACL	Supports L2 to L4 packet filtering function, which can match the first 80 bytes of the message, and provides ACLs defined based on source MAC address, destination MAC address, source IP address, destination IP address, IP protocol type, TCP/UDP port, TCP/UDP port range, VLAN, etc. Supports port-based and VLAN-based ACL issuance
Safety Features	Supports user hierarchical management and password protection Supports port-based IEEE802.1X authentication Supports AAA & RADIUS with TACACS+ authentication Supports MAC address learning number limit Supports MAC address black hole, address binding Support SSH 2.0 to provide secure encrypted channel for user login Supports port isolation Supports ARP message speed limit function Supports IP source address protection Supports ARP intrusion detection Supports anti-DoS attacks Supports port broadcast message suppression Support for host data backup/restore mechanism IP+MAC+VLAN+Port Quad Binding Function
DHCP	Support for DHCP Serve Support for DHCP Client Support DHCP Snooping v1/v2/v3
Management and Maintenance	Support for Web-based network management, CLI command line (Console, Telnet), SNMP (V1/V2c/V3) and other diversified management and maintenance Support for WEB-based network management (HTTP/HTTPS support) Support HTTP, TFTP file upload/download management Supports RMON 1, 2, 3 and 9 groups Support one key to restore factory settings Supports NTP clock and local clock Support for local logs and system logs (SYSLOG) Support Ping detection Supports cable status checking Supports instant CPU utilization status view Supports Link Layer Discovery Protocol LLDP Support NMS platformed cluster unified management (LLDP+SNMP)
System requirements	Web Browser: Mozilla Firefox 2.5 or higher, Google Chrome V42 or higher Category 5 and above Ethernet cables. TCP/IP network adapter and operating system (e.g. Microsoft Windows, Linux or Mac OS)

Strong operational capabilities

Support 128 entries IPV4/IPV6 static/dynamic routes, support ARP protocol, maximum 1024 entries, support IPV4/IPV6 management.
Flexible port bandwidth and traffic configuration, optical port DDMI digital diagnostic function, and easy realization of exemplary network management.
Support IEEE 802.1Q VLAN, support protocol VLAN, and support QinQ VLAN so the user can be flexible according to the needs of VLAN.
It supports QoS, three priority modes based on port 802.1P and DSCP, and four queue scheduling algorithms, Equ, SP, WRR, and SP+WRR.
Supports ACLs, which provide flexible security access control policies by configuring matching rules, processing operations, and time permissions to achieve packet filtering.
Supports IGMP V1/V2/V3 multicast protocol and IGMP Snooping V1/V2/V3 to meet the needs of multi-terminal HD video surveillance and video conference access.
Supports STP/RSTP/MSTP production tree protocols and ERPS fast ring protocols to eliminate Layer 2 loops and realize link backup.
Supports static aggregation and dynamic aggregation (LACP) to effectively increase link bandwidth, achieve load balancing link backup, and improve link reliability.

Complete safety features

Support WEB interface user authentication.
Supports CPU protection to prevent large data streams from attacking the switch itself
Supports 802.1x authentication, remote RADIUS, TACACS+ authentication
The hardware supports IP ACL, MAC ACL, ACL port filtering function, MAC address binding, and port-based IP+MAC+Vlan+Port multiple binding functions.
Support DHCP Snoopingv1/v2/v3, port isolation, and port broadcast storm suppression functions.

Convenient operation and maintenance management

Supports diverse management and maintenance methods such as Web-based network management, CLI command line (Console, Telnet), and SNMP (V1/V2c/V3).
Support HTTP/HTTPS, SSH, and other encryption methods for more secure management.
Support HTTP/TFTP to realize firmware update/upgrade, support configuration file upload/download, and one-key restore system configuration.
Supports RMON, system logs, and port traffic statistics for network optimization and transformation.
Support LLDP, which is convenient for the network management systems to query and judge the communication status of links.
Supports CPU monitoring, memory monitoring, Ping detection, and cable detection.
